Interxion Paris 8-11
Data CentreClient
Interxion
Client PM
Brysk
Architect
DK Architects
Civil Structural Engineers
Hanley Pepper
IT Load
76.8MW
Project Area
Approx 40,000m2
Project Status
Complete
Project Description
This Data Centre facility, located in Paris, France, consists of 4 buildings, namely PAR8, 9, 10 & 11. Each building has an IT capacity of 19.2MW which will be deployed across 3 floors of data halls. The total site IT load is 76.8MW.
Ethos Input
Ethos was responsible for the full M&E design services right through to the detailed design.
Unique / Key Features
Electrical Systems
• 3 separate utility grid connections (Enedis/RTE)
• MV/MV transformers consisting of 20/12.0kV, 20MVA, step-down
• MV/LV transformers, consisting of 12.0/0.42kV, 4MVA, step-down
• 2286kVA/1829kW diesel engine generator plant
• Bulk fuel storage and distribution system
• Power backbone infrastructure
• Earthing system, TN-C/TN-S, lightning protection system
• UPS power distribution, PMS monitoring system
• Generator control system and site switching system
• Fully addressable normal and emergency lighting
• Security systems
• Fire detection and protection, including fire suppression
• Leakage detection and structured cabling
Mechanical Systems
• Water cooled chillers
• CGM’s with chiller integration and hybrid dry cooler integration
• CRAH cooling
• Ventilation and humidity control systems
• Inergen fire suppression system
• Struxureware BMS
• Dedicated smoke extraction systems for data halls and battery rooms
